Product Selection Guide

M12P-5MA-C 5-pin M12 Male Assembled Plug, IDC type, A-coding -
M12P-5FA 5-pin M12 Female Assembled Plug, Soldering type, A-coding -
M12P-5FA-C 5-pin M12 Female Assembled Plug, IDC type, A-coding -
M12P-8MA 8-pin M12 Male Assembled Plug, Soldering type, A-coding -
M12P-8MA-C 8-pin M12 Male Assembled Plug, IDC type, A-coding -
M12P-8FA 8-pin M12 Female Assembled Plug, Soldering type, A-coding -
M12P-8FA-C 8-pin M12 Female Assembled Plug, IDC type, A-coding -
M12P-8MX-C 8-pin M12 Male Assembled Plug, IDC type, X-coding -
M23P-5MA 5-pin M23 Male Assembled Plug, Soldering type, A-coding -
M23P-5MAR-S 5-pin M23 Male Assembled Plug, Screw type, A-coding,right angled -
7/8P-5FA 5-pin 7/8 inch Female Assembled Plug, Soldering type, A-coding -
7/8P-5FAR-S 5-pin 7/8 inch Female Assembled Plug, Screw type, A-coding, right angled -

RF Antenna Base (Magnetic)

Model Name Description Cable Length
N Female Magnetic WLAN RF Antenna Base, Cable length 1.5m, with SMA Male RS
RFB-M2-150 1.5 m
connector
N Female Magnetic WLAN RF Antenna Base, Cable length 10m, with SMA Male RS
RFB-M2-1000 10 m
connector
SMA Female RS Magnetic WLAN RF Antenna Base, Cable length 1.5m, with SMA Male RS
RFB-M3-150 1.5m
connector
Accessories RF Cable
Model Name Description Cable Length
RFC-SFR-SMR-1000 Low loss RF Cable, Cable length 10m, RP-SMA Female to RP-SMA Male connector 10 m
RFC-SF-SMR-150 Low loss RF Cable, Cable length 1.5m, SMA Female to RP-SMA Male connector 1.5 m
RFC-SM-SMR-150 Low loss RF Cable, Cable length 1.5m, SMA Male to RP-SMA Male connector 1.5 m
RFC-NM-SMR-150 Low loss RF Cable, Cable length 1.5m, N Male to RP-SMA Male connector 1.5 m
RFC-NM-SMR-500 Low loss RF Cable, Cable length 5m, N Male to RP-SMA Male connector 5m
RFC-NM-SMR-1000 Low loss RF Cable, Cable length 10m, N Male to RP-SMA Male connector 10 m
RFC-NF-NM-50 Low loss RF Cable, Cable length 0.5m, N Female to N Male connector 0.5 m
RFC-NF-NM-500 Low loss RF Cable, Cable length 5m, N Female to N Male connector 5 m
RFC-NF-NM-1000 Low loss RF Cable, Cable length 10m, N Female to N Male connector 10 m
RFC-NM-NM-150 Low loss RF Cable, Cable length 1.5m, N Male to N Male connector 1.5m

RF Surge Protector

Model Name Description
RFP-NF-NM-WAG High-power RF Surge Protector, 0~6GHz, N Female to N Male connector

RF Adapter
Model Name Description
RFC-SF-SM-0R RF Right Angle Adapter, SMA Female to SMA Male connector
RFC-SFR-SM-0 RF Adapter, RP SMA Female to SMA Male connector
RFC-SFR-SMR-0R RF Right Angle Adapter, RP-SMA Female to RP-SMA Male connector
RFC-SM-NF-0 RF Adapter, SMA Male to N Female connector
RFC-SMR-NF-0 RF Adapter, RP-SMA Male to N Female connector
RFC-SM-NM-0 RF Adapter , SMA Male to N type Male connector
