Product Selection Guide

Industrial
Device Server

IDS-322 IDS-312L
Serial Port
Serial port Numbers 2 1
Serial Mode RS-232/422/485 RS-232/422/485
Serial Port Connector DB9 (male) DB9 (male)
Serial Port with 2KV Isolation - -
Serial Baud Rate 110 bps to 460.8 Kbps 110 bps to 460.8 Kbps
Ethernet Port
10/100Base-T(X) in RJ45 Ports 2 2
10/100/1000Base-T(X) in RJ45 Ports - -
Wireless LAN Interface - -
Support PoE (IEEE 802.3af compliant) ● -
Ethernet Switch mode / Fast Recovery - -
Mode supported
Power Redundancy
DC Terminal Block 2 1
DC Power Jack - -
Installation
DIN-Rail Mounting ● ●
Wall mounting ● ●
Physical Characteristics
Casing Protection IP-30 IP-30
Dimensions (mm) 45(W) x 80.6(D) x 95(H) mm 26(W) x 75(D) x 110(H) mm
Operating Temperature
-40 to 70°C ● ●
-10 to 60°C - -
Networking Technology
Operating Modes Virtual Com, Serial Tunnel, TCP Server, TCP Client, UD Virtual Com, Serial Tunnel, TCP Server, TCP Client, UDP
Windows NT/2000/XP/2003/
Windows NT/2000/XP/2003/
Windows O.S.Supported VISTA 64-Bit/ Windows 7 64-Bit VISTA 64-Bit/ Windows 7 64-Bit
5 host devices : Virtual COM,
Multiple Link TCP Server, TCP Client mode; 5 host devices : Virtual COM, TCP Server, TCP Client mode;
4 IP ranges : UDP 4 IP ranges : UDP
Event Notification Syslog / SMTP/ SNMP trap Syslog / SMTP/ SNMP trap
NAT Router Pass Through - -
PPPoE - -
DDNS - -
Security
HTTPS/SSH Management ● ●
IP White List ● ●
SSL Data Encryption ● ●
IEEE 802.1X - -
Warranty 5 years
