Product Selection Guide

Accessories
Gigabit Ethernet SFP-RJ45 modules

Specifications

Model Name
Characteristics SFP1GRJ SFP1GRJ-I SFP10GRJ
Operating Temperature 0~70°C -40~85°C 0~70°C
RJ45 Operation mode 1000Base-T ＊ 1000Base-T ＊ 10GBase-T
SFP Interface SERDES, 1000Base-X SERDES,1000Base-X SERDES, 10GBase-X
＊1. Please notice 10/100Base-T(X) modes are not supported.
2. Link length up to 100m with Cat5 UTP cable or better.
1. Please notice 10/100/1000Base-T modes are not supported.
2. Link length up to 30m with Cat6a/7 cable.

Ordering Information

Model Name Description
SFP1GRJ 1Gbps SFP to 1000 Base-T transceirer, 0 ~ 70°C
SFP1GRJ-I 1Gbps SFP to 1000 Base-T transceirer, industrial grade, -40 ~ 85°C
SFP10GRJ 10Gbps SFP+ to 10G - Base-T transceirer, 0 ~ 70°C

10G Ethernet SFP+ Copper Cable

Specifications

Model Name
Characteristics SFPC10G-50 SFPC10G-100 SFPC10G-300 SFPC10G-500
Max.Speed 10 Gbps 10 Gbps 10 Gbps 10 Gbps
Wire Guage 30 AWG 30 AWG 30 AWG 24 AWG
Low Smoke ● ● ● ●
Zero Halogen
Cable length 0.5 m 1 m 3 m 5 m
Operating temperature -40 ~ 85°C -40 ~ 85°C -40 ~ 85°C -40 ~ 85°C

Ordering Information

Model Name Description Cable length
SFPC10G-50 10Gbps SFP+ copper cable 30AWG, 0.5 m, -40 ~ 85°C 0.5 m
SFPC10G-100 10Gbps SFP+ copper cable 30AWG, 1 m, -40 ~ 85°C 1 m
SFPC10G-300 10Gbps SFP+ copper cable 30AWG, 3 m, -40 ~ 85°C 3 m
SFPC10G-500 10Gbps SFP+ copper cable 24AWG, 5 m, -40 ~ 85°C 5 m

Get Connected Anytime, Anywhere 131
