Product Selection Guide
Industrial EN50155 Gigabit PoE Ethernet Switch
Unmanaged Switch
Industrial
Ethernet Switch
TSPL-101GT-M12 Series TINJ-101GT-M12 series TINJ-101-M12 series
Port Number
Number of ports 2(M12) 2(M12) 2(M12)
10/100Base-T(X) RJ45 Ports - - 1(M12)
10/100/1000Base-T(X) RJ45 Ports 1(M12) 1(M12) -
PoE+(30 Watts) Ports 1(P.D) 1(P.S.E.) 1(P.S.E.)
PoE++(90 Watts) Ports - - -
100/1G/10G Fiber Ports - - -
Optical Bypass ports - - -
Power Redundancy
DC Terminal Block 1 1 1
DC Power Jack - - -
Operating Voltage 36 to 57 VDC 50-57VDC 12-50VDC 50-57VDC 12-50VDC
Output Power - 30 Watts Max. 30 Watts Max.
Output Voltage 24V@1A 12V@2A - -
Installation
DIN-Rail Mounting - ● ●
Wall Mounting ● ● ●
Physical Characteristics
Casing Protection IP-40 IP-30 IP-30
Dimensions (mm) 88.9(W)x40(D)x178.2(H) 88.9(W)x40(D)x178.2(H) 88.9(W)x40(D)x178.2(H)
Operating Temperature
-10 to 60°C - - -
-25 to 70°C - ● ●
-25 to 75°C ● - -
Network Redundancy
O-Ring - - -
Open-Ring - - -
O-Chain - - -
STP/RSTP - - -
Management and Control
802.1X - - -
Rate Limit - - -
Port Mirror - - -
Port Security - - -
IGMP v2/v3 - - -
QoS Port Base/COS/TOS - - -
Port Trunk Static/LACP - - -
LLDP - - -
System Alarm - - -
DHCP - - -
VLAN - - -
Management / Configuration - - -
Warranty 5 years
