Unmanaged Switch

Industrial
Ethernet Switch

TXES-180-M12 TXES-150-M12 TES-W9124GT-M12X-BP2-24V-IP54
Port Number
Number of ports 8 5 16
10/100Base-T(X) M12 D-Coding Ports 8x10/100/500 5x10/100/500 12
10/100/1000Base-T(X) M12 X-Coding Ports - - 4
100Base-FX Fiber Ports - - -
1000Base-X Fiber Ports - - -
Gigabit Combo Ports - - -
Power Redundancy
On M12 Connector 1(M12) 1(M12) 2(M12)
On M23 Connector - - -
Installation
Wall Mounting ● ● ●
Rack Mounting - - -
Physical Characteristics
Casing Protection IP-30 IP-30 IP-54
Dimensions (mm) 89(W) x 40(D) x 178(H) 89(W) x 40(D) x 178(H) 280(W) x 90(D) x 182(H)
Operating Temperature
-40 to 70°C - - -
-40 to 75°C ● ● ●
Network Redundancy
O-Ring - - ●
O-Chain - - ●
MRP *NOTE - - -
MSTP/RSTP/STP - - ●
Management and Control
802.1X - - ●
Rate Limit - - ●
Port Mirror - - ●
Port Security - - ●
IGMP v2/v3 - - ●
QoS Port Base/COS/TOS - - ●
Port Trunk Static/LACP - - ●
LLDP - - ●
System Alarm - - SYSLOG / SMTP / SNMP Trap
DHCP - - Server / Client / Relay
VLAN - - Port-Based/802.1Q/Q-in-Q/GVRP
Management / Configuration - - WEB / Windows Utility / SNMP v1,v2c,v3 / Telnet / Console
(CLI)
Warranty 5 years

*NOTE: This function is available by request only
