ORing MagiCloud Overview

The ORing MagiCloud is a powerful managed cloud platform designed for industrial applications. With support
for Modbus-RTU and ModBus-TCP, you can easily connect your devices to the platform and interact with cloud
applications and other devices.
The ORing MagiCloud supports billions of devices and routes data to applications or other devices securely and
reliably. Along with the ORing IIoT, REST API will be provided to help you track your device connectivity and access
data from all of your devices anytime, even if they are offline.

ORing IIoT Roadmap

Node-RED SCADA
(Data) (Industrial 4.0)
SaaS
Streetlight Sensors Map Dashboard Reporting Dash board Wizard Data flow design SCADA/HMI/MES Alarming Reporting

North Bound ( Restful API: OAthu2.0 )

3rd Party
Cloud Platform
PaaS API
Account Thing Big data Data Logger Security AI engine Network Rule Engine
Management Management Analysis Management (tensor flow) Management
South Bound ( Protocols: MQTT/MQTT-Sparkplug/COAP/LWM2M )

IOT Cloud Interface
Gateway IGMG IMG ORIO ( Wireless Interfaces: 3G/4G/NB-IOT/CAT-M1/ Lora WAN ) Streetlight
master

Device Interface
Ethernet AP ( Serial/Ethernet/DIDO/AIAO/BLE/LoRa P2P )
Switch
Things
Streetlight
slaves

Functional Block

PaaS

Account Thing Big data Data Logger Security AI engine Network Rule Engine
Management Management Analysis Management (tensor flow) Management
